Yunnan Manual Gap-Bed Lathe - Great Condition
Metal working
CY6250B x 2000
China China
2001 United Arab Emirates
Machine Details
Item Details
| Name | Yunnan Manual Gap-Bed Lathe - Great Condition |
|---|---|
| Item Code | SM2605749 |
| Model No | CY6250B x 2000 |
| Serial No | 10051227 |
| Usage | used |
| Industry | Metal working |
| Manufacturer | China |
| Year of Manufacture | 2001 |
| Country of Origin | China |
| Posted On | 05-05-2026 |
| Machine Location | United Arab Emirates |
Description
Ideal for both shaft work and large disc/plate machining.
features an induction-hardened bed for long-term accuracy and a rapid feed system to maximize productivity.
The design allows for the removal of a section of the bed to accommodate larger diameter workpieces (up to 710mm).
In excellent working condition.
Contact now for viewing and inspection of the machine.
Technical Specifications
| Swing Over Bed | 500mm |
|---|---|
| Swing Over Cross Slide | 300mm |
| Swing in Gap | 710mm |
| Distance Between Centers | 2000mm |
| Spindle Bore | 82mm |
| Spindle Speed Range | 9 – 1600 RPM (24 steps) |
| Spindle Nose | D8 Camlock |
| Main Motor Power | 7.5 kW (Standard) |
| Voltage/Phase | 380V / 3-Phase |
| Tailstock Taper | MT 5 |
| Thread Cutting | Metric, Inch, Module, and DP Threads |
| Weight (Approx.) | 2,800 kg – 3,000 kg |
