Brand new
Testex TF164B Air Permeability Tester
Clothing and Apparel
TF164B
Testex China
2021 United Arab Emirates
SM2504173
Machine Details
Item Details
| Name | Testex TF164B Air Permeability Tester |
|---|---|
| Item Code | SM2504173 |
| Model No | TF164B |
| Serial No | -- |
| Usage | new |
| Industry | Clothing and Apparel |
| Manufacturer | Testex |
| Year of Manufacture | 2021 |
| Country of Origin | China |
| Posted On | 09-04-2025 |
| Machine Location | United Arab Emirates |
Description
Air Permeability Tester, widely used to test the resistance of fabrics (woven, knitted and non-woven textile materials) to the passage of air (airflow), the test textile is firmly clamped by a specified rig of selected test head/area to resist the constant air pressure settled before the permeability test.
Features:
Can be controlled by the touch panel
The result of air permeability test is displayed on the touch panel, units can be shifted
Equipped with printing function
Equipped with analyzing software.
Technical Specifications
| Power | 220/110V 50/60Hz |
|---|---|
| Weight | 129 kg |
| Dimensions | 790 x 620 x 1270 mm (L x W x H) |
| Standard Test Heads | 20cm2 and 38cm2 |
| Measuring Range | 1~12000mm/s (L/m2.s) |
| Test pressure | 1 ~ 4000Pa |
| Max thickness of specimen | ≤ 8mm |
| Measuring accuracy | <+/-2% |
| Standards | ASTM D737, ISO 9237 |
