The newly designed low-stress and high-strength frame cuts overall stress by 51% and effectively prevents fatigue breakage compared to similar products. Hydro-pneumatic suspension technology replaces leaf springs, significantly enhancing machine comfort and lifespan, solving frequent front suspension spring failures, and improving operational attendance. It features superior shock absorption and damping to improve frame load handling and durability. The front oil and gas suspension significantly upgrades buffering and vibration control, reducing impact forces on the frame, cab, and heavy parts, lowering fault occurrence, and extending vehicle life.

Parameters
Net Weight: 32T
Engine Model: Weichai WP12G460E310
Gearbox Type: Fast 7DS200
Capacity (Struck/Heaped): 31/35m³
Size: 8970x3470x4310mm
Left/Right Hand Drive: Left/Right
Total Power: 338kW
Displacement: 11.6L
Maximum Torque: 2000NM
Max. Gradeability: 30%
Min. Turning Radius: 11000mm
Number/Type of Cylinders: 6/ straight line
Lubrication System: Optional automatic lubrication
Automatic/Manual: Manual
Axle: 20+35+35
Tyre: 14.00R25
Load Weight: 60T


Price: AED 1468000
