Item Details

Description

Features
The oil and gas suspension system at the front has been greatly enhanced to better absorb shocks and vibrations, decreasing the impact on critical components like the frame and cab. This improvement reduces fault occurrence and extends the vehicle's service life, effectively eliminating front plate spring fractures. The vehicle's full hydraulic steering system alleviates heavy steering challenges found in large trucks and includes an emergency steering function to handle failures caused by engine flameout or pump issues. The intelligent electrical system employs a SANY module that can self-diagnose and address faults automatically.

Parameters
Net Weight: 37T
Gearbox Type: Dual 3-shift AMT
Capacity (Struck/Heaped): 33/38m³
Size: 9145x3660x4395mm
Left/Right Hand Drive: Left/Right
Total Power: 740kW
Maximum Torque: 2300NM
Max. Gradeability: 39%
Min. Turning Radius: 12500mm
Lubrication System: Optional automatic lubrication
Automatic/Manual: Automatic
Axle: 25+35+35(t)
Tyre: 16.00R25
Load Weight: 60T


Price: AED 1460000
