OIL MOLECULAR DISTILLATION PLANT
Pharmaceutical
ZEAN Spain
2024 Spain
Machine Details
Item Details
| Name | OIL MOLECULAR DISTILLATION PLANT |
|---|---|
| Item Code | SM26101333 |
| Usage | new |
| Industry | Pharmaceutical |
| Manufacturer | ZEAN |
| Year of Manufacture | 2024 |
| Country of Origin | Spain |
| Posted On | 30-10-2026 |
| Machine Location | Spain |
Description
Short-path evaporator with a 5 m² heat exchange surface area. Constructed from stainless steel. Still in its original packaging. COMPLETE DOCUMENTATION.
Main dimensions:
Outer diameter: 500 mm. Total height: 5,600 mm.
Roller type: consists of 8 rows of rollers made of PTFE reinforced with glass fiber.
Includes an anti-splash system to prevent contamination of the distilled product.
Design temperature: 280 ºC.
Process temperature: 250 ºC.
Design pressure (bar): -1/4.
Material of construction (process/utility): SS 316L / SS 304.
Motor power: 4 kW, 1500 rpm, IP-55. Voltage: 400 V, 3-phase, 50 Hz.
Includes a double mechanical seal and a sealing circuit, consisting of an internal reservoir, recirculation pump, level indicator, and pressure gauge.
Electrical classification: non-ATEX classified zone.
COMPONENTS:
DEGASSING UNIT
VACUUM TRAP (DEGASSING STAGE)
VACUUM TRAP (SHORT-PATH STAGE)
CONCENTRATE TANK
DISTILLATE TANK
VACUUM SYSTEM (DEODORIZER)
VACUUM SYSTEM (SHORT-PATH)
